Ebike Colour SW900 LCD Display Control Electric Bicycle Speed Meter 36-72V
Ebike Colour SW900 LCD Display Control Electric Bicycle Speed Meter 36-72V
Can work with our MQ & YF controllers
Display Function:
- Speed display, power-assisted gear display, power indicator, fault prompt, total mileage, single mileage, headlights and single driving time display.
Control/Setting Function:
- Power switch control, headlight switch control, 6Km/h boost control, wheel diameter setting, speed limit setting, meter sleep setting, backlight brightness setting, voltage setting.
Harness Description:
- Red (P+) meter power cord
- Blue (VCC) electric door lock wire
- Black (GND) negative wire
- Green (RX) Meter data receiving
- Yellow (TX) Meter data transmission
Meter Setting Function：
- Long press the up and down buttons of the meter to enter the meter settings.
- P01: Backlight brightness, level 1 is the darkest, level 3 is the brightest.
- P02: Mileage unit, 0: KM; 1: MILE.
- P03: Voltage level: 24V, 36V, 48V.
- P04: Sleep time: 0, no sleep; other numbers are sleep time, range: 1-60; unit minutes.
- P05: Power assist gear 1-9
- P06: Wheel diameter: unit, inch; precision: 0.1.
- P07: Number of speed magnets: range: 1-100.
- P08: Speed limit: speed percentage range 0-100%, 100 means speed 100%.
- P09: Zero start, non-zero start setting, 0: zero start; 1: non-zero start.
- P10: Drive mode setting 0: power-assisted drive (the handle is invalid).
1: Electric drive (by turning the handle to drive, the power gear is invalid at this time).
2: Power-assisted drive and electric drive coexist at the same time.
- P11: Assist sensitivity setting range: 1-24.
- P12: Assist start intensity setting range: 0-5.
- P13: Power-assisted magnet type setting There are three types of 5, 8, and 12 magnets, of which 5 and 8 are single Hall power-assisted sensors.
- Setting 12 is used for dual Hall assist sensors.
- P14: This function is not available yet.
- P15: This function is not available yet.
- P16: ODO reset setting, Long press the up button for 5 seconds ODO
Package Includes:
1 X SW900 Display Colour
